Desempeño

Localización adecuada:Carcasa del ordenador
Tipo:Kit de refrigeración líquida
Diámetro de ventilador:12 cm
Sockets de procesador soportados:LGA 1150 (Zócalo H3), LGA 1151 (Zócalo H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1366 (Socket B), LGA 1700, LGA 2011 (Socket R), LGA 2066, LGA 775 (Socket T)
Procesador compatible:Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9
Velocidad de rotación (mín.):900 RPM
Velocidad de rotación (máx.):2750 RPM
Compatible con modulación por ancho de pulsos (PWM):Si
Conector de bomba:3 pines
Cantidad por paquete:1 pieza(s)
Velocidad de motor de bomba (min):2250 RPM
Velocidad de motor de bomba (max):2750 RPM
Velocidad del ventilador (min):900 RPM
Velocidad de ventilador (max):1800 RPM
Productos compatibles:Compatibilidad con Intel: LGA 775 / 1200 / 1151 / 1150 / 1155 / 1156 / 1366 / 1700 / 2011 / 2066 Compatibilidad con AMD: AM4 / AM5

Diseño

Color del producto:Negro
Material:Aluminio
Material de radiador:Aluminio
Base material de la placa:Cobre
Número de ventiladores:2 Ventilador(es)
Iluminación LED:Si
Iluminación de color:Multi
Tipo de conector LED:3 pines
Conector de ventilador:4 pines
Material de bloque de agua:Cobre
Certificación:This symbol indicates that electrical appliances should not be discarded with other household waste. Used equipment sho- uld be handed over to a local collection point for this type of waste or to a recycling center. Please contact your local authorities for information about disposal methods available in your area. Wa- ste electrical equipment may contain hazardous substances (e.g. mercury, lead, cadmium, chromium, phthaltes) which can get into air, soil and groundwater when leaking from used appliances. Environmental pollution with these substances leads to their bio- accumulation, causing lesion of disease in living organisms, which would pose a risk to human and animal health or life. Households may contribute to environmental protecion by proper waste collection. In such way, hazardous substances from the equipment are neutralized and valuable secondary raw materials are reused for production of new equipment.

Puertos e Interfaces

Número de conectores SATA:1

Control de energía

Potencia de diseño térmico (TDP):250 W

Peso y dimensiones

Ancho:205 mm
Longitud del tubo:40 cm
Anchura de la bomba:15 cm
Altura:450 mm
Peso:1,53 kg
Ancho del paquete:20 mm
Profundidad del paquete:15 mm
Altura del paquete:35 mm
Peso del paquete:1,97 kg

Características técnicas:Technical specification: • TDP: 250 W • Cooling standard: 240 mm • Radiator dimensions: 277 × 120 × 27 mm • Cooling pipes length: 400 mm • Heat sink material: Aluminium • Water block base material: Copper • Number of fans: 2 × 120 mm • Fan power connector: 4-pin (PWM) (male + female) • Fan LED connector: 3-pin (male + female) • Pump power connectors: 3-pin • Pump LED connector: 3-pin (male + female) • Fan speed: 900 - 1800 RPM • Pump speed: 2250 - 2750 RPM • Intel compatibility: LGA 775 / 1200 / 1151 / 1150 / 1155 / 1156 / 1366 / 1700 / 2011 / 2066 • AMD compatibility: AM4 / AM5 • Set contents: Radiator with pump, 2 × 120 mm fans, mounting accessories, thermal paste, user manual

Periodo de garantía:2 año(s)

Certificados de conformidad:CE

Advertencia de seguridad:Safety conditions for heat sink and fan • Use the product in accordance with its intended use, as im- proper use may damage the product. • Do not expose the device to moisture. • The device should be cleaned only with a dry cloth. • Independent repairs and modification result automatic loss of the warranty. • Hitting or dropping may damage the product.
